Nader A

Our current fleet consists of two Livestock Carrier Mv Nader A and Mv Bruna. The vessels has been newly converted to Livestock Carrier in 2013 and 2016 by our conversion team in Tripoli, Lebanon and Tuzla, Turkey under the direct supervision of our General Manager.

NAME NADER - A

EX-NAME YOUZARSIF H

IMO 7611547

YEAR OF BUILT 1977, CONVERTED 2013

PLACE OF BUILT J.J. SIETAS SCHIFFSWEFT, HAMBURG

TYPE LIVESTOCK CARRIER

FLAG TOGO

PORT OF REGISTRY LOME

CALL SIGN 5 V C D 3

MMSI 671 371 000

CLASS INTERNATIONAL NAVAL SURVEYS BUREAU - I.N.S.B.

P&I CLUB RAETS MARINE

AGREEMENT CERTIFICATE FOR LIVESTOCK VESSEL SETE, FRANCE, AUTHORIZATION UNTIL 05.06.2018 DEAD WEIGHT 2,103.27 MT

DISPLACEMENT 2,417.73 MT

GRT 2,160 MT

NRT 1,309 MT

L.O.A 81.39 M

L.B.P 74.16 M

BREADTH 13.42 M

SUMMER DRAFT 5.90 M

AVERAGE SPEED 10/13 KNOTS

TRADING AREA A1, A2, A3

NUMBER OF DECKS 5 DECKS 2241 SQM FOR SHEEPS/CATTLE

ABOUT 7000/8000 HEADS OF SHEEP ABOUT 1250 HEADS OF CATTLE AT 600 KGS ABOUT 1100 BIG CAMELS+ABOUT 170 SMALL CAMELS CAMELS CAN BE LOADED 5 HEADS TOGETHER

CAN LOAD CAMELS, HORSES, SHEEP, LAMBS, CATTLE, COWS, BULLS ETC DECKS HEIGHTS / CARGO AREA

1ST DECK: 2.30 M ------------------------- 409 SQM 2 GENERATORS SCANIA, DIS 14, 250 KW

2ND DECK: 3.10 M ------------------------- 465 SQM 2 GENERATORS DEUTZ, F5L 413, 50 KW

3RD DECK: 2.40 M ------------------------- 511 SQM 22 VENTILATION FANS, 770,000 CBM/H

4TH DECK: 2.40 M ------------------------- 541.5 SQM 1 MAIN ENGINE, MAK 453, 2560 HP

5TH DECK: 2.10 M ------------------------- 314.5 SQM 1 FRESH WATER GENERATOR, 55 MTONS/DAY STRAW AND FODDER SPACES: 712.8 CBM 1 FRESH WATER GENERATOR, 8 MTONS/DAY 2 CRANES, 4MTONS SWL FRESH WATER TANKS: 400 MTONS USABLE

AUTOMATIC DRINKING SYSTEM 24 HOURS/DAY 2 DRINKING PUMPS, 30 MTONS/HOUR, 7 KW EACH

2 HATCHES, FWD 3.00M X 2.40M, AFT 1.20M X 4.00M BOTH HATCHES ARE REACHABLE BY THE 2 CRANES

NAME	BRUNA
EX-NAME	YOUZARSIF II
IMO	7601073
YEAR OF BUILT	1977, CONVERTED 2016
PLACE OF BUILT	J.J. SIETAS SCHIFFSWEFT, HAMBURG
TYPE	LIVESTOCK CARRIER
FLAG	TOGO
PORT OF REGISTRY	LOME
CALL SIGN	5 V E G 7
MMSI	671 177 000
CLASS	INTERNATIONAL NAVAL SURVEYS BUREAU - I.N.S.B.



P&I CLUB	RAETS MARINE
AGREEMENT CERTIFICATE FOR LIVESTOCK VESSEL	SETE, FRANCE, AUTHORIZATION UNTIL 20.12.2021
DEAD WEIGHT	1802.31 MT
DISPLACEMENT	2718.69 MT
GRT	2912 MT
NRT	1568 MT
L.O.A	81.39 M
L.B.P	74.16 M
BREADTH	13.40 M
SUMMER DRAFT	5.95 M
AVERAGE SPEED	10/13 KNOTS
TRADING AREA	A1, A2, A3
NUMBER OF DECKS 5 DECKS	2297.3 SQM FOR SHEEPS/CATTLE
ABOUT 7000/8000 HEADS OF SHEEP	ABOUT 1300 HEADS OF CATTLE AT 600 KGS
ABOUT 1100 BIG CAMELS+ABOUT 170 SMALL CAMELS	CAMELS CAN BE LOADED 5 HEADS TOGETHER
CAN LOAD CAMELS, HORSES, SHEEP, LAMBS, CATTLE, COWS, BULLS ETC
DECKS HEIGHTS / CARGO AREA
1ST DECK: 3.10 M ------------------------- 400 SQM	2 GENERATORS CATERPILLAR, 3412.12V, 400 KW
2ND DECK: 2.40 M ------------------------- 461.81 SQM	2 GENERATORS DEUTZ, F6L 413R, 80 KW
3RD DECK: 2.40 M ------------------------- 499 SQM	1 GENERATOR VOLVO, D103, 200 KW
4TH DECK: 2.40 M ------------------------- 545 SQM	21 VENTILATION FANS, 1,835,000 CBM/H
5TH DECK: 2.10 M ------------------------- 391.5 SQM	1 MAIN ENGINE, MAK 453, 2560 HP
STRAW AND FODDER SPACES: 712.8 CBM	1 FRESH WATER GENERATOR, 55 MTONS/DAY
1 FOODER SILO, 160 MTONS	1 FRESH WATER GENERATOR, 10 MTONS/DAY
2 CRANES, 6.5 MTONS SWL	FRESH WATER TANKS: 400 MTONS USABLE
AUTOMATIC DRINKING SYSTEM 24 HOURS/DAY	2 DRINKING PUMPS, 30 MTONS/HOUR, 7 KW EACH
2 HATCHES, FWD 3.00M X 2.40M, AFT 1.20M X 4.00M	BOTH HATCHES ARE REACHABLE BY THE 2 CRANES
